Description
DISCONTINUED - FLIR T600
The Best Ergonomics and an Economical New Thermal Resolution for Intensive Inspections
Inspect high and low comfortably all day and capture stunning shots effortlessly with the latest addition to thermal imaging's most flexible line of handheld cameras.
A New High IR Resolution – Crisp thermal images with 172,800 pixels (480 × 360) for the better detection, pictures, and temperature measurements from long range.
Exclusive Rotating Optical Block – Work smarter. Scan targets overhead, under objects, and from tough angles effortlessly with the help of a lens system that lets you point 120° up or down while keeping the display in easy view.
MSX® Enhancement – Multi-Spectral Dynamic Imaging adds visible spectrum definition to IR images in real time for excellent thermal detail to help you instantly recognize the problem locations.
Remote Control and Streaming Video via Wi-Fi – Control camera functions, stream video for live monitoring, and import images and data from the camera using the FLIR Tools Mobile app on your smartphone or tablets so you can share critical information quickly from the field.
Auto-Focus Precision – FLIR T-Series cameras offer both manual control and the fastest auto-focus in the industry to snap in ultimate clarity and accuracy.
GPS and Compass – Automatically adds geo-location data and camera pointing direction to images to include in reports.
Accuracy – Calibrated within +/– 2°C or +/– 2% of reading.
Multiple Measurements – Report all the details with 10 measurement spots, 5 box areas, Delta T temperature differential, isotherm, and auto hot/cold markers.
METERLiNK® – Wirelessly transmit vital diagnostic data from clamp and moisture meters directly to the camera for annotating thermal images to further support findings.
Specs
| Temperature range | -40°F to 1202°F (-40°C to 650°C) |
|---|---|
| Thermal sensitivity (N.E.T.D) | <0.04°C at 30°C |
| Digital Zoom | 4X Continuous |
| Focus | Manual or Automatic (one shot) |
| LCD Image Sketch | Draw on stored images using the touchscreen |
| Multi-Spectral Dynamic Imaging (MSX) | IR image with enhanced detail presentation |
| Frame Rate | 30Hz |
| Field of view/Minimum focus distance/FOV Match | 25° x 19° / 0.82ft (0.25m) / Field of View Match where Digital Image FOV adapts to the IR lens |
| Detector Type - Focal plane array (FPA) uncooled microbolometer | 480 x 360 pixels |
| Lens | 30Hz |
| Display | Built-in touch-screen 4.3" color LCD (800 × 480 pixels) |
| Image modes | Thermal/Visual/Fusion/P-i-P/MSX (Resizable and movable ) and Thumbnail Gallery |
| Automatic image adjustment | Continuous/manual; linear or histogram based; possible to lock max, min or span temperature |
| Manual image adjustment | Level/span/max/min |
| Image Storage | 1000 radiometric JPEG images (SD card memory) |
| Image annotation | Voice (60 sec); text comments, Sketch |
| Periodic image storage | 7 seconds to 24 hours (IR) and 14 seconds to 24 hours (IR and visual) |
| Video Lamp and Laser Pointer | Built-in dual LED lamps plus onboard laser pointer |
| Laser Classification/Type | Class 2/Semiconductor AlGalnP Diode Laser: 1mW/635nm (red) |
| Set-up controls | Mode selector, color palettes, configure info to be shown in image, local adaptation of units, language, date and time formats, and image gallery |
| Measurement modes | 10 Spotmeters, 5 Box areas, Isotherm, Auto hot/cold spot, Delta T |
| Measurement correction | Reflected ambient temperature & emissivity correction |
| GPS | Location data automatically added to every image from built-in GPS |
| Compass | Indicates direction camera is pointing for target documentation |
| Video Recording in Camera and Video Streaming | Non-radiometric IR-video recording (MPEG-4 to memory card), Visual and Radiometric IR-video streaming (Full dynamic to PC using USB or Wi-Fi), and Non-radiometric IR-video streaming (MPEG-4 using Wi-Fi and uncompressed colorized video using USB) |
| Battery Type/operating time | Li-lon/ 2.5 hours, Display shows battery status |
| Charging system | In camera AC adapter/2 bay charging system |
| Shock / Vibration / Encapsulation; Safety | 25G, IEC 60068-2-29 / 2G, IEC 60068-2-6 / IP54; EN/UL/CSA/PSE 60950-1 |
| Dimensions/Weight | 5.6 x 7.7 x 3.7" (143x196x94mm)/2.87lbs (1.3kg), including battery |
| Accessories included | SD Memory Card, 100-260V AC adapter/charger, two Li-Ion rechargeable batteries, 2-bay battery charger, power supply (with multi-plugs), FLIR Tools software, USB cable, video cable, Bluetooth® headset, lens cap, neckstrap, and hard case |
| Shock / Vibration / Encapsulation; Safety | 25G, IEC 60068-2-29 / 2G, IEC 60068-2-6 / IP54; EN/UL/CSA/PSE 60950-1 |
| Dimensions/Weight | 5.6 x 7.7 x 3.7" (143x196x94mm)/2.87lbs (1.3kg), including battery |
