Description
NAVAC NMV1 Micron Vacuum Gauge
Precise Measurement
This gauge uses a Pirani high-precision vacuum sensor to precisely measure vacuum levels. Digital display affords a comprehensive view of vacuum conditions. When reaching the preset vacuum level, it will buzz as a reminder. When the vacuum level decreases from the preset vacuum level, it will buzz rapidly and flash the backlit to warn of leaks.
Key Features:
- Ergonomic design
- Precision vacuum sensor
- Large backlit display
- Buzzing alert
Specs
| Maximum overload pressure | 72 psi |
| Range | 0 ~ 10000 Pa 0 ~ 100 mBar 0 ~ 75 mmHg 0 ~ 75000 microns |
| Resolution | 0.01 (10Pa) 0.0001 (10mBar) 0.0001 (10mmHg) 1 (30000microns) |
| Accuracy | 15 - 750 micron: ±5% of reading (at 68°F) |
| Operating temperature | 32~122°F(0 ~ 50°C) |
| Units | Pa, mBar, mmHg, Microns |
| Sensor | Pirani sensor |
| Buzzer alarm | 90 db, shut down after 10 seconds |
| Weight | 4.5 oz |
| Warranty | 1 year |
Includes
- (1) NMV1 Micron Vacuum Gauge
- (1) Brass Coupler and Tee
- (3) AAA Batteries
- (1) Cloth Pouch
Resources
NAVAC NMV1 Manual
