Description
Aspen FP3400/MG Silent+ Mini White Condensate Removal Pump, Gen 5
Compact, ultra-quiet condensate pump for mini-split installations
The Aspen Silent+ Mini White Gen 5 sets the new benchmark in condensate removal for mini-split systems. Delivering whisper-quiet operation at just 16dB(A)—this next-generation pump incorporates Aspen's proven 5th Gen variable speed technology to intelligently match performance to system demand. Engineered for Silence.
Aspen mini condensate pumps are engineered for reliable, low-noise operation in noise-sensitive environments such as offices, hotels, and residential spaces. Designed around a total system approach, each pump includes everything needed for installation. Advanced capacitance sensor technology resists dirt, dust, and biofilm, minimizing maintenance beyond routine system service. Backed by industry-leading warranties up to 3 years, Aspen mini pumps deliver long-term performance installers can trust.
Key Features & Benefits
- Ultra-quiet operation as low as 16 dB(A) for quiet indoor installs
- Adaptive variable-speed technology for smooth, on-demand condensate removal
- Max flow up to 12 US Gal/hr (45 L/h) with recommended head up to 33 ft / 10 m
- Compact, discreet design fits behind wall units or in tight spaces
- Removable reservoir for easy cleaning and maintenance
- Universal 100-250 VAC power for flexible installs
- Self-priming pump with IP24 protection for long-life performance
- Includes power cable, fittings, spacer, anti-siphon device, and quick start guide
Specs
| FP3400/MG Mini White 5.0 Specs | |
|---|---|
| Max Flow Rate | 12 Gallons/hr @0 m head |
| Max Unit Output | 157,000 BTU/h / 13 tons / 46 kW |
| Max Recommended Head | 33 ft |
| Inlet O.D. | 5/8" (Ø16 mm) |
| Outlet O.D. | 1/4" (Ø6 mm) |
| Sound Level @ 3 ft | As low as 21dB |
| Max Water Temperature | 104 °F |
| Self-Priming | Yes |
| Color | White |
| Warranty | 3 year |
Includes
- (1) Silent+ Mini White 5.0 Gen Pump
- (1) Hardwired 5ft (1.5m) Power Cable
- (1) Fitting template (on the box)
- (1) Spacer
- (1) Outlet coupler
- (1) Outlet elbow
- (1) Anti siphon device
- (1) Quick Start Guide
Aspen Silent+ Mini White Manual
