Description
Klein Tools TI250 Rechargeable Pocket Sized Thermal Imaging Camera
Quickly identify hot and cold spots with compact 19,200 pixel images
The Klein Tools TI250 is an easy-to-use, USB rechargeable Thermal Imager. The large LCD displays unseen hot and cold spots for instant troubleshooting. Excellent resolution with over 19,200 pixels and your choice of three color palettes. The meter provides high and low temperature points, crosshairs to pinpoint specific temperatures, and options for temperature alarms. Easily capture and transfer images with USB-C port for reporting.
Key Features & Benefits
- Thermal imager with over 19,200 pixels for identifying hot and cold spots
- Adjustable emissivity from 0.01 to 0.99 for accurate temperature readings
- Store and share captured images via USB-C connection
- User selectable high and low temperature alarms from -4 °F to 752 °F (-20 °C to 400 °C)
- Selectable color palettes to better visualize temperature differences
- Rechargeable lithium-ion battery
- Includes thermal imager, charging cable, carrying case, and instructions
Specs
| Klein Handheld Thermal Imager Specs | |
|---|---|
| Application | View hot and cold spots for instant troubleshooting |
| Special Features | High and low temperature points, crosshairs for pinpoint temperature measurement, temperature alarm options, three color palettes |
| Display | 2.4" (6.1 cm) TFT LCD |
| Display Resolution | 320 x 240 pixels |
| Sensor Type | VOx microbolometer |
| Sensor Resolution | 19,200 pixels |
| Thermal Sensitivity | <60 mK |
| Spectral Range | 8 to 14 µm |
| Temperature Range | -4 °F to 752 °F (-20 °C to 400 °C) |
| Accuracy |
Above 212 °F (100 °C): ±2 ° or 2% (whichever is greater) Below 212 °F (100 °C): ±3 ° or 3% (whichever is greater) |
| Field of View | 50° ±3° |
| Emissivity | 0.01 to 0.99 adjustable |
| Color Palettes | Ironbow, Rainbow, Grayscale |
| Photo Capture | Yes |
| Maximum Frame Rate | <9 Hz |
| Memory | Internal 32 GB |
| Battery | Rechargeable lithium-ion |
| Included | Thermal imager, charging cable, carrying case, instructions |
| Overall Length | 3.1" (8.0 cm) |
| Overall Width | 1" (2.5 cm) |
| Overall Height | 3.1" (8.0 cm) |
| Weight | 8.5 oz (241 g) |
| UPC | 092644692932 |
Includes
- (1) Klein Tools TI250 Rechargeable Pocket Sized Thermal Imaging Camera
- (1) Charging Cable
- (1) Carry Case
Resources
Klein TI250 Thermal Imager Manual
