Description
NAVAC NEF6LM Cordless Power Flaring Tool 3/4" Max OD
Quick and accurate flaring. Ultra light.
A welcome departure from creating flares manually, the NEF6LM Cordless Power Flare yields accurate, hassle-free flares in a fraction of the time compared to traditional flaring methods. Weighing less than 3 pounds, the new Power Flaring Tool equips with a high-performance rechargeable lithium battery which makes over 100 flares per charge. NAVAC's second-generation automatic flaring solution is significantly reduced in weight and price without sacrificing accuracy or consistency. Designed to perform reliably in harsh environments, the NEF6LM Cordless Power Flare also allows one-button, one-hand operation. In addition, it features a battery power indicator and a flashlight It comes in a sturdy blow-molded case with five commonly-sized flare dies, one battery, a charger, and a premium flare gauge.
Key Features & Benefits:
- Complete a flare in 15 seconds
- Over 100 flares per charge
- Quick charge in 30 minutes
- Ultra light at 2.9 lbs
- Quick connect with ready-to-use clamps
- 45° flaring for R410A
- Limit baffle assures precise flare depth
- Easy one-button operation
- Battery power indicator
- LED flash light
- Includes a NAVAC NFG1 Flaring Gauge
- Replacement clamps are available: 5/16" NAQC1, 1/4" NAQC2, 3/8" NAQC3, 1/2" NAQC4, 5/8" NAQC5, 3/4" NAQC6
Specs
| Tubing Type | Copper |
| Tubing OD | 1/4", 3/8", 1/2", 5/8", 3/4" |
| Power | DC Motor |
| Cone Speed | 120 RPM |
| Battery Capacity | Up to 100 flares per charge |
| Time to flare | Under 30 seconds |
| Dimensions | 10" x 4" x 4" |
| Weight | 2.9lbs |
| Battery | 7.4V 2Ah 14.8W |
| Quick Charge | 30 minutes |
Includes
- (1) NAVAC NEF6LM Cordless Power Flaring Tool
- (1) Battery with charger
- (1) NAVAC NFG1 Flaring Gauge
- (1) Hard Case
- (1 ea.) Flare heads (1/4", 3/8", 1/2", 5/8", 3/4")
Videos
Resources
NAVAC NEF6LM Manual
