Description
Testo 868s Thermal Imaging Camera 160 x 120 with SuperResolution and Smart App
Smart and networked thermography
Thermography connected - with the testo 868s thermal imager. It has the best thermal image quality in its class, an integrated digital camera, and stands out thanks to smart new features with intuitive operation in a modern tile look. The testo Thermography App turns your smartphone or tablet into a second display. In addition to this, you can operate the imager with the App as well as creating and sending reports on site.
Features and Benefits
- Infrared resolution 160 x 120 pixels with testo SuperResolution technology 320 x 240 pixels
- Testo Thermography App for on-site analysis and report generation
- Thermal sensitivity (NETD) of < 0.14 °F (0.08 °C) (80 mK)
- Automatic detection of hot and cold spots
- testo ScaleAssist for comparable images in building thermography
- Integrated 5 MP digital camera
- IFOV warner for displaying the measurement spot size
Specs
| Infrared image output | |
|---|---|
| Infrared resolution | 160 x 120 pixels |
| Thermal sensitivity (NETD) | <0.14 °F (0.08 °C) (80 mK) |
| Field of view/min. focusing distance | 31° x 23° / < 1.6 ft (0.5 m) |
| Geometric resolution (IFOV) | 3.4 mrad |
| testo SuperResolution (Pixel/IFOV) | 320 x 240 pixels 2.1 mrad |
| Image refresh rate | 9 Hz |
| Focus | Fixed focus |
| Spectral range | 7.5 to 14 µm | Image presentation |
| Image size / min. focus distance | 5 MP / min. 1.6 ft (0.5m) |
| Image display | 3.5 in (8.9 cm) TFT, QVGA |
| Display options | IR image / real image |
| Color palettes | iron, rainbow HC, cold-hot, grey | Data interfaces |
| Wi-Fi | Yes, Communication with the testo Thermography Ap, Wireless module Wi-Fi |
| USB 2.0 Micro B | Yes | Measurement |
| Measuring ranges | Measuring range 1: -22 to 212°F (-30 to +100 °C) Measuring range 2: 0 to 1,202 °F (0 to +650 °C) Manual/automatic switchover |
| Accuracy | ±3.6 °F (±2 °C), ±2 % of measurement value (larger value applies) |
| Emissivity / reflected temperature compensation | 0.01 to 1 / manual |
| Testo ε-assist | Automatic recognition of emissivity and determination of reflected temperature (RTC) | Measurement functions |
| Analysis functions | Centre point measurement, hot/cold spot detection, delta T |
| testo ScaleAssist | Yes |
| IFOV warner | Yes | Imager equipment |
| Digital Camera | Yes |
| Lens | 31° x 23° |
| Video streaming | via USB, via Wi-Fi with App |
| Storage as JPG | Yes |
| Fullscreen mode | Yes | Image storage |
| File format | .bmt and .jpg; export options in .bmp, .jpg, .png, .csv, .xls |
| Memory | Internal memory (2.8 GB) | Power supply |
| Battery type | Li-ion battery can be changed on-site |
| Operating time | 4 hours |
| Charging options | In instrument/in charging station (optional) |
| Power Supply Included | Yes | General Specs |
| Operating temperature range | 5 to 122 °F (-15 to +50 °C) |
| Storage temperature range | -22 to 140 °F (-30 to +60 °C) |
| Air humidity | 20 to 80 %RH, not condensing |
| Housing protection class (IEC 60529) | IP54 |
| Weight | 1.12 lbs (510 g) |
| Dimensions (LxWxH) | 8.6 x 3.8 x 3.7 in (219 x 96 x 95 mm) |
Includes
- (1) Testo 868s Thermal Imaging Camera 160 x 120 with SuperResolution
- (1) Wi-Fi Radio Module (Smart App Compatible)
- (1) Hard Case
- (1) USB Cable
- (1) Power Supply
- (1) Li-Ion Rechargable Battery
- (1) Pro Software (free download)
- (1) Quick start guide
- (1) Calibration certificate
Videos
Resources
 Product Datasheet |
Software / App
Download the Testo Thermography App for your Android or iOS devices today!
App for the thermal imagers testo 868, testo 871, testo 872 and testo 883: mobile, flexible, efficient.
App Features
- See a live image from the thermal imager in the App
- Remote control of the thermal imager via the App
- Transmission of stored images from the thermal imager to the App
- Analyze thermal imagers and add comments
- Create reports quickly and easily
- Send images or reports by e-mail or share via Cloud services
